SOB962060

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 2X25A/400VAC/2 CTRL 3.5-32VDC Configured with screw Terminals and Normally Open Contacts and Hockey Puck Housing with 3,5VDC - 32VDC @ <13mA Max . Celduc Part Number SOB962060

$76.60

Min: 19  Mult: 19

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-55 to +100

Overall Dims (HxLxW)

(1.18 x 2.34 x 1.76)

Packaging Type

Carton

Number of switched phases

2 phase - 2 controls

Terminals

screw

Switching type relay

ZC

Contact

Normally Open

Load Current Max (calibre relais)

25

Housing

Hockey Puck

Load Voltage Min

24

Load Voltage Max

600

Length-mm

59.4

Height-mm

30

Width-mm

44.8

Load continuous current (nominal)

35

EAN

3760283300064

Not available at this time.
