SOB863860

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 2X35A/400VAC/2 CTRL 17-30VAC/DC Configured with screw Terminals and Normally Open Contacts and Hockey Puck Housing with 17VAC - 30VAC @ Max . Celduc Part Number SOB863860

$102.60

Min: 19  Mult: 19

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-55 to +100

Overall Dims (HxLxW)

(1.18 x 2.34 x 1.76)

Packaging Type

Carton

Number of switched phases

2 phase - 2 controls

Control voltage (nominal)

24VAC

Switching type relay

ZC

Load Current Max (calibre relais)

40

Housing

Hockey Puck

Terminals

screw

Contact

Normally Open

Load Voltage Min

24

Load Voltage Max

600

Length-mm

59.4

Height-mm

30

Width-mm

44.8

Load continuous current (nominal)

35

EAN

3760283300866
