SO941440

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 12A/12-280VAC/TVS/CTRL 3-32VDC/LED/INPUT CURRENT LIMITER Configured with screw Terminals and Normally Open Contacts and Hockey Puck Housing with 3VDC - 32VDC @ <13mA Max . Celduc Part Number SO941440

$28.40

Min: 19  Mult: 19

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-40 to +100

Overall Dims (HxLxW)

(1.18 x 2.34 x 1.76)

Packaging Type

Carton

Number of switched phases

1 phase

Control voltage (nominal)

5-12-24VDC

Switching type relay

ZC

Terminals

screw

Protection

TVS

Contact

Normally Open

Load Current Max (calibre relais)

12

Housing

Hockey Puck

Load Voltage Min

12

Load Voltage Max

280

Length-mm

59.4

Height-mm

30

Width-mm

44.8

Load continuous current (nominal)

12

EAN

3760283308978

Not available at this time.
