SO842974

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 25A/12-275VAC/VDR/CTRL 20-265VAC/DC/LED/REGULATED INPUT/IP20 Configured with screw Terminals and Normally Open Contacts and Hockey Puck Housing with 20VAC/18VDC - 265VAC/240VDC @ 10mA Max . Celduc Part Number SO842974

$37.90

Min: 19  Mult: 19

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-55 to +100

Overall Dims (HxLxW)

(1.18 x 2.34 x 1.76)

Packaging Type

Carton

Number of switched phases

1 phase

Control voltage (nominal)

110-230VAC/24-48-110VDC

Switching type relay

ZC

Terminals

screw

Protection

VDR

Contact

Normally Open

Load Current Max (calibre relais)

25

Housing

Hockey Puck

Load Voltage Min

12

Load Voltage Max

275

Length-mm

59.4

Height-mm

30

Width-mm

44.8

Load continuous current (nominal)

25

EAN

3760283301832
