SO469420

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 125A/400VAC CTRL 4-20 MA Configured with screw Terminals and Normally Open Contacts and Hockey Puck Housing with @ 50mA Max . Celduc Part Number SO469420

$209.90

Min: 2  Mult: 2

Product Attributes


Click Here

Temperature Range

-40 to +100

Manufacturers direct Page

Click Here

Overall Dims (HxLxW)

(1.18 x 2.3 x 1.77)

Number of switched phases

1 phase

Packaging Type

Carton

Terminals

screw

Switching type relay

phase angle controller

Protection

VDR

Contact

Normally Open

Load Current Max (calibre relais)

125

Housing

Hockey Puck

Load Voltage Min

200

Load Voltage Max

480

Length-mm

58.5

Height-mm

30

Width-mm

45

EAN

3760283302037
