SO445420

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 50A/230VAC/CTRL 4-20MA Configured with screw Terminals and Normally Open Contacts and Hockey Puck Housing with @ 20mA Max . Celduc Part Number SO445420

$138.90

Min: 2  Mult: 2

Product Attributes


Click Here

Temperature Range

-40 to +90

Manufacturers direct Page

Click Here

Overall Dims (HxLxW)

(1.18 x 2.3 x 1.77)

Number of switched phases

1 phase

Packaging Type

Carton

Terminals

screw

Switching type relay

phase angle controller

Protection

VDR

Contact

Normally Open

Load Current Max (calibre relais)

50

Housing

Hockey Puck

Load Voltage Min

100

Load Voltage Max

280

Length-mm

58.5

Height-mm

30

Width-mm

45

EAN

3760283302907

Not available at this time.
