SKL10521

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 50A/230VAC/CTRL 3-14V/RANDOM Configured with pin Terminals and Normally Open Contacts and PCB Housing with 3VDC - 14VDC @ 19,5mA Max . Celduc Part Number SKL10521

$39.40

Min: 20  Mult: 20

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-40 to +80

Overall Dims (HxLxW)

(0.96 x 1.72 x 0.25)

Control voltage (nominal)

12VDC

Packaging Type

Tube

Number of switched phases

1 phase

Terminals

pin

Switching type relay

Random

Contact

Normally Open

Housing

PCB

Load Voltage Min

12

Load Voltage Max

280

Length-mm

43.6

Height-mm

24.5

Width-mm

6.3

Load continuous current (nominal)

30

EAN

3760283308114

Not available at this time.
