SKL10240

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 25A/400VAC/CTRL 4-14V/450A²S Configured with pin Terminals and Normally Open Contacts and PCB Housing with 4VDC - 14VDC @ 30mA Max . Celduc Part Number SKL10240

$40.10

Min: 20  Mult: 20

Product Attributes


Click Here

Temperature Range

-40 to +80

Manufacturers direct Page

Click Here

Overall Dims (HxLxW)

(0.96 x 1.72 x 0.25)

Number of switched phases

1 phase

Control voltage (nominal)

12VDC

Packaging Type

Tube

Terminals

pin

Switching type relay

ZC

Contact

Normally Open

Housing

PCB

Length-mm

43.6

Height-mm

24.5

Width-mm

6.3

Load continuous current (nominal)

25

EAN

3760283308138

Not available at this time.
