SKB20420

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 5A/230VAC/CTRL 8-30V Configured with pin Terminals and Normally Open Contacts and PCB Housing with 8VDC - 30VDC @ 24mA Max . Celduc Part Number SKB20420

$13.30

Min: 100  Mult: 100

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-40 to +100

Overall Dims (HxLxW)

(1 x 1.7 x 0.4)

Packaging Type

Tube

Number of switched phases

1 phase

Control voltage (nominal)

12VDC

Switching type relay

ZC

Load Current Max (calibre relais)

5

Housing

PCB

Terminals

pin

Contact

Normally Open

Load Voltage Min

12

Load Voltage Max

280

Length-mm

43.2

Height-mm

25.4

Width-mm

10.2

Load continuous current (nominal)

4

EAN

3760283308213

Not available at this time.
