SKA10420

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 5A/230VAC/CTRL 2.5-10V Configured with pin Terminals and Normally Open Contacts and PCB Housing with 2,5VDC - 10VDC @ 27mA Max . Celduc Part Number SKA10420

$24.50

Min: 20  Mult: 20

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-40 to +100

Overall Dims (HxLxW)

(1 x 1.7 x 0.4)

Packaging Type

Tube

Number of switched phases

1 phase

Control voltage (nominal)

5VDC

Switching type relay

ZC

Terminals

pin

Protection

VDR

Contact

Normally Open

Load Current Max (calibre relais)

5

Housing

PCB

Load Voltage Min

12

Load Voltage Max

275

Length-mm

43.2

Height-mm

25.4

Width-mm

10.2

Load continuous current (nominal)

4

EAN

3760283308329
