SILD845160

Celduc | Solid State Relay
green-check-icon Total Stock: 2
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 32A/70-275VAC/CTRL 3-32VDC/1500A²S/DIAGNOSTIC Configured with screw Terminals and Normally Open Contacts and DIN Rail Housing with 3-32VDC @ <10mA Max . Celduc Part Number SILD845160

$86.50

Min: 1  Mult: 1

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-40 to 80

Overall Dims (HxLxW)

(4.57 x 3.15 x 0.89)

Packaging Type

Carton

Number of switched phases

1 phase

Control voltage (nominal)

5-12-24VDC

Switching type relay

ZC

Load Current Max (calibre relais)

32

Housing

DIN Rail

Terminals

screw

Contact

Normally Open

Load Voltage Min

70

Load Voltage Max

280

Length-mm

80

Height-mm

116.1

Width-mm

22.5

Load continuous current (nominal)

32

EAN

3760283307377

Not available at this time.
