SCM0100200

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 100A - 200VDC - CTRL 4,5-32VDC Configured with screw Terminals and Normally Open Contacts and Hockey Puck Housing with 4,5VDC - 32VDC @ Max . Celduc Part Number SCM0100200

$224.20

Min: 2  Mult: 2

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-40 to +90

Overall Dims (HxLxW)

(1.1 x 2.29 x 1.75)

Control voltage (nominal)

5-12-24VDC

Packaging Type

Carton

Terminals

screw

Housing

Hockey Puck

Load Current Max (calibre relais)

100

Contact

Normally Open

Load Voltage Min

A définir

Load Voltage Max

A définir

Length-mm

58.2

Height-mm

28

Width-mm

44.5

EAN

3760283305618

Not available at this time.
