SC864810

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 50A/400VAC/CTRL 17-60VAC Configured with screw Terminals and Normally Open Contacts and Hockey Puck Housing with 17VAC/VDC - 80VAC/VDC @ 26mA Max . Celduc Part Number SC864810

$70.40

Min: 38  Mult: 38

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-40 to +100

Overall Dims (HxLxW)

(1.06 x 2.29 x 1.75)

Packaging Type

Carton

Number of switched phases

1 phase

Control voltage (nominal)

24VAC/24VDC

Switching type relay

ZC

Terminals

screw

Protection

RC

Contact

Normally Open

Housing

Hockey Puck

Load Voltage Min

12

Load Voltage Max

280

Length-mm

58.2

Height-mm

27

Width-mm

44.5

Load continuous current (nominal)

50

EAN

3760283307124

Not available at this time.
