SC842110

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 25A/230VAC/CTRL 4-30VDC Configured with screw Terminals and Normally Open Contacts and Hockey Puck Housing with 4VDC - 30VDC @ 30mA Max . Celduc Part Number SC842110

$52.30

Min: 38  Mult: 38

Product Attributes


Click Here

Temperature Range

-40 to +100

Manufacturers direct Page

Click Here

Overall Dims (HxLxW)

(1.06 x 2.29 x 1.75)

Number of switched phases

1 phase

Packaging Type

Carton

Terminals

screw

Switching type relay

ZC

Protection

RC

Contact

Normally Open

Housing

Hockey Puck

Load Voltage Min

12

Load Voltage Max

280

Length-mm

58.2

Height-mm

27

Width-mm

44.5

Load continuous current (nominal)

25

EAN

3760283307162
