Product Attributes

Current

24A @ 300V

Torque

0.5 Nm

Strip length

6.5mm

Spacing

5.00mm

Pin Dim.

1mm x 0.8mm

PCB thickness

max 2.4mm

PCB holes

min 1.4mm

Operating Temp

-40C to +110C

Material Terminal

Copper alloy, Tin plated

Material Screw

M3, copper alloy, Ni plated

Material Housing

Polyamide 6,6 (UL94V-0)

Material Clamp

Copper alloy, Ni plated

List Price@Factory Min

2.08

Wire Range

12 to 30 AWG

Not available at this time.
