Product Attributes

Color

Green

Torque

0.25Nm

Strip length

5mm

Spacing

3.5mm

Pin Dim.

0.9mm x 0.5mm

PCB thickness

max 1.8mm

PCB holes

min 1.1mm

Operating Temp

-40C to +110C

Material Terminal

Copper alloy, Ni plated

Material Screw

M2, copper alloy, Ni plated

Material Housing

Polyamide 6,6 (UL94V-0)

Material Clamp

Copper alloy, Ni plated

List Price@Factory Min

1.62

Current

12A @ 300V

Wire Range

14 to 30 AWG

Not available at this time.
