Price List
MSB04001-ON
Total Stock: 409
Factory Lead Time: TBD
RoHs Compliant
EB 04P 5.00mm Black Blockmaster PN: MSB04001-ON
Hawk Electronics
Total Stock: 409
Factory Lead Time: TBD
RoHs Compliant
Product Attributes
Color
Black
Torque
0.5 Nm
Strip length
5mm
Spacing
5.00mm
Positions
4
Pin Dim.
.9mm x 0.5mm
PCB thickness
max 2.4mm
PCB holes
min 1.1mm
Operating Temp
-40C to +110C
Material Terminal
Copper Alloy, Tin-plated
Material Screw
M3, Copper Alloy, Ni plated
Material Housing
Polyamide 6,6 (UL 94V-O)
Material Clamp
Copper Alloy, NI plated
List Price@Factory Min
0.71
Current
13.5A @ 300V
Wire Range
16-30 AWG
Series Attributes
Not available at this time.
