Price List
CIF03B01-SPCL
Factory Lead Time: TBD
RoHs Compliant
PB 03P 5.00mm Green Marked ABC Blockmaster PN: CIF03B01-SPCL
Hawk Electronics
Factory Lead Time: TBD
RoHs Compliant
Product Attributes
Color
Green
Torque
3.5 in-lb
Strip length
6mm
Spacing
5.00mm
Positions
3
Material Spring
Phosphorus bronze,Tin plated
Material Screw
M3, copper alloy, Ni plated
Material Housing
Polyamide 6,6 (UL94V-0)
Material Clamp
Copper alloy, Ni plated
List Price@Factory Min
0.84
Insertion force
max 3 N
Current
12A @ 300V
Wire Range
12 to 30 AWG
Series Attributes
Not available at this time.
