Product Attributes

Handle

Castle

Pushbutton Contact Resistance

N/A

Pushbutton Electrical Rating

N/A

Pushbutton Electrical Life

N/A

Pushbutton Dielectric Strength

N/A

Pushbutton Stop Strength

N/A

Pushbutton Contact arrangement

N/A

Optional Mating Harness Part No.

4 function harness p/n 505-508

Operation Force

3.1 N +/- 0.5 N

Operating Temp

-40C to + 85C

Pushbutton Terminal Material

N/A

Storage Temp

-40C to + 85C

Pushbutton Insulation Resistance

N/A

Mounting Style

Drop-In and Rear Mount

Sealing

IP68 and IP69 (does not prevent panel ingress)

Termination

1.00mm Pitch Molex connector

Limiter

4-way

Contact

Silver Plated

Lifecycles

100,000 operations

Current/Voltage Rating with Resistive Load

100mA @ 30VDC

Contact Resistance

Max 200 milliohms

Voltage Withstand

500VAC for 1 minute

Termination Product Range

Pico-Clasp

Termination Pitch

1.00mm

Termination MFG P/N

501331-0607

Termination MFG

Molex

Termination Mating connector P/N

501330-0600

Operating Force

5.56N +/- 0.53N

Mechanical Life

300,000 Operations

Max Vertical Load

200N

Max Horizontal Load

150N

Lever Travel

30 degrees

Insulation Resistance

Min 100 Megaohms

Electrical Function

Mom-Off-Mom

Wire Type for Optional Mating Harness

28AWG 25cm PTFE
