Product Attributes

Actuator Shape

Round, High

Electrical Function

Normally Open (NO)

Operating Force

6N

Terminals

Flying Leads

Actuator Color

Red

Additional Options

N/A

Actuator Material

Polyamide 6/6

Operating Temp

-40C to + 85C

Output Type

NPN

Packaging unit

25 pieces

Sealing

Front Panel, IP67 according to EIC 60529

Supply Current

VDC = 12V : 2.5mA max (Current consumption in off position)

Supply Voltage

3.5VDC to 24VDC

Switch Function

No-Mom

Torque

1.5 Nm max applied to nut

Total Travel

1.80 mm (.070) +/- 0.3 mm

Multi-wire lead

AWG26, 150 mm

Minimum Panel Thickness

1.5 mm (0.059)

Bezel Material

Zinc die-cast (zamac), black painted

Bushing Material

Zinc die-cast (zamac), black painted

Case Material

PBT, UL94-V0

Function

Single

Hardware Supplied

1 hex nut 14mm (.551) across flats and 1 O-ring. Hex nut part number-U166

Max Output Current

50mA

Max Output Voltage

24VDC

Maximum Panel Thickness

4mm (0.157)

Mechanical Life

5 million cycles

Typical Operating Force

6N +/- 2N
