IFS3Z1AD200

Apem | IF | Pushbutton
green-check-icon Total Stock: 40
yellow-timer-icon Factory Lead Time: 112
onlycheckmark RoHs Compliant
IF
APEM 16mm Round Threaded Bushing Push button switch with Black Actuator and Black body and gold pltd silver QC Term.

$29.70

Min: 20  Mult: 20

Product Attributes

Mounting

Threaded Bushing

Front Panel Seal

IP 67

Actuator Color

Black

Case Color

Black

Actuator Material

Polyamide 12 rubber filled

Total Travel

4 mm

Torque

11.5Nm Max applied to nut

Terminal Seal

Epoxy

Soldering

320C Max for 3 Seconds

Operating Temperature

-20C to +85C

Max Current

400 mA 32VAC - 100mA 48VDC

Low Level Mechnical Life

1,000,000 Cycles

Insulation resistance

1 GOhms min at 500VDC

Initial contact Resistance

50 mOhms Max

Hex Nut P/N

10-621

Electical Life

500,000 Cycles at full load

Contact Material

Solid Silver, Gold Plated

Case Material

Thermoplastic UL94-V0

Bushing/Bezel Material

Polyamide 6/6

Typical Operating force

6.5 N +/- 2N
