filter--iconPrice List

Product Attributes

Pricing Note

Price change of approx. 3.0% Effective 07/03/23

Lead Time (weeks)

52

APEM PROD GROUP

V977

Factory Notes

Engineering working on redesign solution - TBD

Handle

Tapered (2 Axis)

Limiter Plate

Square

Mounting

Drop in

Output

0.5V to 4.5V Sensor 1 -- 4.5V to 0.5V Sensor 2

Break Out Force X & Y Axis

1.3N

Maximum Applied Force X & Y Axis

200N

Mechanical Angle of Movement X & Y Axis

36 Degrees

Operating Force X & Y Axis

2.8N

Operating Temperature

-40C to +85C

Operating Torque Z Axis

0.121Nm

Output Impedance

2 Ohms

Output Linearity

+-200mV

Package Size

5.75" x 4.50" x 3.25"

Sensor

Hall effect

Maximum Allowable Torque Z Axis

2.50 Nm

Materials

Glass Filled Nylon

Break Out Torque Z Axis

0.09N m

Dual Output interlinearity (x/y)

+-400mV

Dual output interlinearity (z)

+-600mV

EMC Emissions Level

EN61000-6-3:2001

EMC Immunity Level (V/M)

EN61000-4-3

ESD

EN61000-4-2

Hand Mechanical Angle Z Axis

60 Degrees

Handle Action Z Axis

Spring Centering, Rotational

Lever Action

Single Spring Omnidirectional

Supply Voltage Operating

5VDC+-0.01VDC
