Product Attributes

Hawk Stock

5 reported as of 02/06/24

Factory Stock

3100 reported as of 02/06/24

Overall Length(mm)

54

Seal Rating

IP68 with Optional Seal Ring

Inner Diameter Gland side

18.5

Inner Diameter Dome side

18.5

Clamping Range (mm)

7-16

Type Thread

NPT

Ext. Thread Length(mm)

15

Color

Black

Outer Diameter Threading

26.7

Nut Flat Dim (mm)

33

Material Seal

Neoprene

Material Body

Polyamide 6

UL File

E184471

VDE

Yes

Overall Dims

1.299 x 1.299 x 2.126

Operating Temperature

-40C to + 100C

Hardware

Locknuts sold separately

Not available at this time.
