Product Attributes

Hawk Stock

5 reported as of 02/06/24

Factory Stock

7600 reported as of 02/06/24

Overall Length(mm)

44

Seal Rating

IP68 with Optional Seal Ring

Inner Diameter Gland side

12.5

Inner Diameter Dome side

12.5

Clamping Range (mm)

3-9

Type Thread

NPT

Ext. Thread Length(mm)

14

Color

Black

Outer Diameter Threading

21.2

Nut Flat Dim (mm)

24

Material Seal

Neoprene

Material Body

Polyamide 6

UL File

E184471

VDE

Yes

Overall Dims

0.945 x 0.945 x 1.732

Operating Temperature

-40C to + 100C

Hardware

Locknuts sold separately
