Product Attributes

Factory Stock

1600 reported as of 02/06/24

Clamping Range (mm)

1.5-6

Overall Length(mm)

38

Seal Rating

IP68 with Optional Seal Ring

Inner Diameter Gland side

8.7

Inner Diameter Dome side

8.5

Type Thread

NPT

Ext. Thread Length(mm)

11

Color

Light Gray

Outer Diameter Threading

17.1

Nut Flat Dim (mm)

19

Material Seal

Neoprene

Material Body

Polyamide 6

UL File

E184471

VDE

N/A

Overall Dims

0.748 x 0.748 x 1.496

Operating Temperature

-40C to + 100C

Hardware

Locknuts sold separately

Not available at this time.
