filter--iconPrice List

Product Attributes

Hawk Stock

5 reported as of 02/06/24

Factory Stock

10 reported as of 02/06/24

Overall Length(mm)

68

Seal Rating

IP68 with Optional Seal Ring

Inner Diameter Gland side

48.5

Inner Diameter Dome side

48.5

Clamping Range (mm)

26-39

Type Thread

Metric

Ext. Thread Length(mm)

12

Color

Light Gray

Outer Diameter Threading

63

Nut Flat Dim (mm)

70

Material Seal

Neoprene

Material Body

Polyamide 6

UL File

E184471

VDE

Yes

Overall Dims

2.756 x 2.756 x 2.677

Operating Temperature

-40C to + 100C

Hardware

Locknuts sold separately

Not available at this time.
